What are Nonyl Phenol Ethoxylates?
Nonyl phenol ethoxylates are nonionic surfactants produced by reacting nonyl phenol with ethylene oxide (EO) under alkaline catalysis, mole by mole, inside a pressurised reactor. The branched C9 alkyl chain on the phenol ring supplies the oil-loving half of the molecule, while the polyoxyethylene chain built during ethoxylation supplies the water-loving half:
C9H19–C6H4–OH + n(C2H4O) → C9H19–C6H4–O–(C2H4O)n–H
(Nonyl phenol reacting with n moles of ethylene oxide; CAS 9016-45-9)
The "n" in NP-n is the average number of EO moles added per mole of nonyl phenol, and it is the single variable that governs almost everything about the finished surfactant — HLB, cloud point, water solubility, even physical form. At the low end (NP-2 to NP-6) the product is an oily, almost water-insoluble liquid; by NP-15 and above it's a waxy paste or solid that disperses freely in water. NP-9 and NP-10 sit squarely in the middle of that range, which is exactly why they're the two grades most commonly specified for general-purpose emulsification, wetting and detergency work, and why they get compared so often.
What is NP-9?
NP-9 (9 moles EO, manufactured by Rishit Polysurf as PLXOL N 900) is the more lipophilic of the two grades, with an HLB of 12.9. At 25°C it's a pale yellow liquid, clear to slightly hazy, with a hydroxyl value of 85–100 mg KOH/g, moisture ≤0.5%, pH (1% aqueous) of 5.5–7.5, and a cloud point of 50–55°C.
That cloud point matters more than the number suggests. Below roughly 50°C, NP-9 stays fully dispersed in water; push the bath hotter and the surfactant begins to come out of solution. In practice, this makes NP-9 the workhorse grade for moderate-temperature aqueous systems — alkaline metal degreasers, ambient-temperature textile scouring, and as a primary emulsifier in emulsion-polymerisation recipes — where its slightly stronger oil affinity gives it an edge in lifting greases and stabilising non-polar monomers.
What is NP-10?
NP-10 (10 moles EO, PLXOL N 1000) carries one more mole of ethylene oxide than NP-9, which nudges HLB up to 13.3 and lifts the cloud point to 52–58°C. The hydroxyl value drops slightly to 76–92 mg KOH/g, reflecting the longer, more hydrophilic polyoxyethylene chain attached to the same C9 phenol backbone. At room temperature it's a clean pale yellow liquid, with moisture and pH specifications matching NP-9.
The practical effect of that small shift is a few extra degrees of thermal headroom and marginally better cold-water dispersibility. Formulators reach for NP-10 when a process runs a touch hotter than NP-9 can comfortably tolerate — high-temperature scouring and dyeing baths, for example — or when a formulation needs slightly more hydrophilic character to balance a low-HLB co-surfactant in a blend.
NP-9 vs NP-10 Comparison Table
| Parameter | NP-9 (PLXOL N 900) | NP-10 (PLXOL N 1000) |
|---|---|---|
| EO Moles | 9 | 10 |
| HLB Value | 12.9 | 13.3 |
| Appearance (25°C) | Pale yellow, clear to slightly hazy liquid | Pale yellow liquid |
| Moisture | ≤ 0.5% | ≤ 0.5% |
| pH (1% aqueous) | 5.5–7.5 | 5.5–7.5 |
| Hydroxyl Value | 85–100 mg KOH/g | 76–92 mg KOH/g |
| Cloud Point (1% aq.) | 50–55°C | 52–58°C |
| Colour (APHA) | ≤ 60 | ≤ 60 |
| Surface Tension | ~31 mN/m | ~31 mN/m |
| Pour Point | −1°C | +2°C |
| CAS No. | 9016-45-9 | 9016-45-9 |
| Overall character | Slightly more lipophilic | Slightly more hydrophilic |
Both grades share the same general pH range, moisture spec and surface tension, which is exactly why they're so often discussed as a pair. The real decision usually comes down to two numbers: HLB and cloud point.
HLB Value Comparison
HLB (Hydrophilic–Lipophilic Balance) is a 0–20 scale describing how water-loving or oil-loving a nonionic surfactant is. Low values (roughly 3–6) suit water-in-oil emulsions, mid values (around 8–15) suit oil-in-water emulsification and wetting, and higher values (15 and above) lean toward detergency and solubilisation. NP-9 (12.9) and NP-10 (13.3) both land inside the oil-in-water emulsifier band, which is exactly why either grade can technically work in many of the same formulations.
The 0.4-point gap between them is small but not irrelevant. NP-9's slightly lower HLB gives it relatively more lipophilic character — useful when the oil phase being emulsified is fairly non-polar, such as mineral oils or waxes — while NP-10's marginally higher HLB gives it a small edge wherever the system needs to lean more hydrophilic, such as stabilising slightly polar oils or improving rinse-off in a wash formulation.
Because HLB is an additive property, both grades are also routinely blended with lower-mole products like NP-4 or NP-6 to dial a formulation into a precise target HLB, rather than relying on a single off-the-shelf grade. This is standard practice in agrochemical EC and emulsion-polymerisation work, where the target HLB is often a fraction outside what any single commercial grade offers on its own.
Emulsification and Wetting Performance
In practice, the HLB and cloud-point gap between NP-9 and NP-10 shows up in three places:
- Oil-cutting power: NP-9's slightly higher lipophilicity gives it marginally stronger detergency against mineral oils and machining greases, which is one reason it shows up so often in alkaline metal cleaners and degreaser formulations.
- Thermal stability: NP-10's higher cloud point (52–58°C vs. 50–55°C) provides a wider safety margin before the surfactant clouds out of solution — useful in hot scouring baths, summer storage, and high-ambient-temperature transport and warehousing.
- Water dispersibility: NP-10 disperses a little faster and more completely in cold-to-warm water, which can simplify make-up of dilute working baths on the plant floor.
Neither difference is dramatic in isolation — formulators routinely substitute one grade for the other with only minor adjustment to dosage or co-surfactant ratio. But in a tightly tuned recipe running close to its operating limits, the wrong choice is often the difference between a stable bath and one that clouds, separates or redeposits soil onto the substrate.
Applications of NP-9
- Alkaline metal cleaners and degreasers — NP-9's oil-cutting strength lifts machining oils and petroleum-based soils even in high-caustic, high-electrolyte wash formulations.
- Emulsion polymerisation — alongside NP-4 and NP-6, NP-9 is a standard nonionic emulsifier for acrylic latex, vinyl-acetate latex and SBR-type systems, prized for its electrolyte tolerance.
- Agrochemical EC formulations — used as an emulsifier and co-solvent in emulsifiable-concentrate insecticides, fungicides and herbicides, helping the active ingredient disperse cleanly at spray-tank dilution.
- Metalworking fluid formulation — functions as the primary emulsifier in soluble and semi-synthetic cutting and coolant fluids.
Applications of NP-10
- Textile wet processing — NP-10 takes over scouring and dyeing-assistant duty in baths that run a few degrees hotter than NP-9 can comfortably tolerate, reducing the risk of mid-process clouding.
- Agrochemical EC formulations — often blended alongside lower-mole grades where a marginally more hydrophilic emulsifier improves spray-tank and dilution stability.
- Paints and coatings — used as a pigment-dispersing and wetting agent in water-borne industrial paints, primers and architectural coatings.
- Industrial and institutional cleaning concentrates — suited to formulations intended for slightly warmer wash or rinse conditions than a standard NP-9-based cleaner.
How to Select the Right Grade
- Match cloud point to process temperature. Keep at least 5–10°C of margin between your maximum operating temperature and the surfactant's cloud point. If your bath runs hot, NP-10 — or a custom blend — is the safer starting point.
- Calculate your target HLB. If your system needs an HLB outside the 12.9–13.3 window, blend NP-9 or NP-10 with a lower-mole grade such as NP-4 or NP-6; HLB combines additively across a blend.
- Check your destination market. Nonylphenol and its ethoxylates are restricted under REACH Annex XVII in the EU above a 0.1% concentration threshold for most industrial and institutional uses (0.01% for textile articles). For EU-facing supply chains, ask our team about REACH-compliant alternatives such as Card Phenol Ethoxylates or Lauryl Alcohol Ethoxylates.
- Weigh cost against performance. NP-9 and NP-10 are priced closely; the deciding factor is almost always thermal margin and HLB fit rather than raw material cost.
- When in doubt, ask. Our technical team can recommend a single grade or a custom NP-9/NP-10 blend based on your oil phase, process temperature and electrolyte load.
Packaging
Both grades are manufactured at our GIDC Dholka facility under in-house quality control and supplied in 200 kg barrels or bulk ISO tank/flexi-tanker loads; smaller sample quantities can be arranged on request through our technical sales team.
Conclusion
NP-9 and NP-10 are close cousins on the nonylphenol ethoxylate ladder, separated by one mole of ethylene oxide, 0.4 HLB units, and a handful of degrees of cloud point. That gap is small enough that either grade can often substitute for the other, and large enough to matter the moment a process runs hot, an emulsion is tightly tuned, or a formulation needs to hit a precise HLB target.
Rishit Polysurf LLP manufactures both grades — along with the complete PLXOL™ range from NP-2 to NP-40 — at our ethoxylation facility in GIDC Dholka, Gujarat, with in-house testing on every batch. If you're not sure whether NP-9, NP-10 or a custom blend is right for your formulation, contact our technical sales team or call +91 83206 81017 for grade selection support, samples, TDS/MSDS and bulk pricing.
